Our FM044 Milling Machine is designed to machine heat exchanger caps, tube sheets, key ways, grooves, and divider plates with many more diverse applications. The milling rail, complete with attached support pillars is installed in position on the face to be machined. Adjustments are made by using the three adjusting screws located in the base of each pillar. In some cases it will be necessary to make a mounting fixture, to secure the rail to the work piece.
The machine can be utilised at any location having a suitable air supply (not less than 7bar, 140 cfm). We can achieve a variety of surface finishes in both the vertical and horizontal milling positions.
Our FM3772 In-Frame Milling Machine was designed in house to machine gearbox bases, pump bases, motor bases, key ways, gasket faces and grooves. Featuring linear rails, the FM3772 provides faster set-up time, increased precision and greater repeatability.
The FM3772, complete with mounting base, is installed in position on the face to be machined. Adjustments are made by adjusting screws on the base of the machine next to each mounting bolt. This machine can be utilised at any location having a suitable air supply (not less than 7bar, 140 cfm). We can achieve a variety of surface finishes in a vertical and horizontal milling position.
The advantage we have compared to other companies is that we can machine a large area in one setting.
